Carolina
|
Category: |
Single Family Dwelling (Private Residence) |
|
SKU: |
221020 |
|
Bedrooms: |
4 |
|
Baths: |
5 |
|
Heated Square Feet: |
4073 |
|
Unheated Square Feet: |
1314 |
|
Total Square Feet: |
5386 |
|
Style: |
Lake House, Modern |
|
Levels: |
2 Story |
|
Covered Parking: |
Garage - 2 Car |
|
Width: |
60'-6" |
|
Depth: |
95'-0" |
|
Height: |
31'-7" |
|
Ceiling Height (Notes): |
8'-0", 10'-0", Vaulted ceiling (as indicated), Slope (as indicated) |
|
Roof Pitch: |
3:12, 8:12, 12:12 |
|
Roof Type: |
Shed (Skillion) |
|
Key Words: |
Bonus, Fireplace - Wood Burning, Mud, Office, Pantry, Study Nook |
|
Foundation Type: |
Crawl Space Foundation |
|
Exterior Wall Type: |
2x6 Wood Studs |
|
