Kitwe Ridge
|
Category: |
Single Family Dwelling (Private Residence) |
|
SKU: |
200611 |
|
Bedrooms: |
4 |
|
Baths: |
3.5 |
|
Heated Square Feet: |
2827 |
|
Unheated Square Feet: |
306 +503 patio |
|
Total Square Feet: |
3656 |
|
Style: |
Barndominium, Modern |
|
Levels: |
2 Story |
|
Covered Parking: |
No covered parking |
|
Width: |
68'-0" |
|
Depth: |
47'-6" |
|
Height: |
20'-9" |
|
Ceiling Height (Notes): |
9'-0", Vaulted ceiling (as indicated) |
|
Roof Pitch: |
3:12, 6:12 |
|
Roof Type: |
Gable, Shed (Skillion) |
|
Key Words: |
Attic Storage, Den (2nd living room), Mud, Pantry, Study Nook |
|
Foundation Type: |
Stem Wall Foundation |
|
Exterior Wall Type: |
2x6 Wood Studs |
|
{{variant.name}}:
|
{{opt.name}}
{{opt.name}}
|
Description
Purchasing options for this design coming soon.
